Common UL Single Conductor Style Types
Hook up and lead wire cable UL style Common UL Single Conductor Style Types
1007, 1015, 1028, 1061, 1180, 1213, 1283, 1284, 1371 1422, 1423, 1429, 1430, 1431, 1452, 3173, 3266, 3271, 3321
Somos Especialistas en Cables. Distribuimos en toda la Republica Mexicana: Innovative Trade Center, Tel: (664) 621 33 36 / 621 30 09 ventas@innovative.com.mx, soporte@innovative.com.mx, Tijuana, B. C. www.innovative.com.mx
Common UL Single Conductor Style Types
| UL Style | Voltage Rating (AC Max.) | Temperature Rating (Max.) | Size Range (AWG/kcmil) | Insulation Type |
| 1007 | 32-16V | 80°C | 32/16 | PVC |
| 1015 | 600V | 105°C | 32/2000 | PVC |
| 1028 | 600V | 105°C | 22/06 | PVC |
| 1061 | 300V | 30-16 Semirigid | 30/16 Semirigid | PVC |
| 1180 | 300V | 200°C | 32/10 | TFE |
| 1213 | N/A | 105°C | 36/16 | TFE |
| 1283 | 600V | 105°C | 8/2 | PVC |
| 1284 | 600V | 105°C | 8/1000 | PVC |
| 1371 | N/A | 105°C | 36/6 | TFE/FEP |
| 1422 | N/A | 105°C | 32/20 | PVDF |
| 1423 | N/A | 105°C | 36/20 | PVDF |
| 1429 | 150V | 80°C | 32/16 | XLPVC |
| 1430 | 300V | 105°C | 30/16 | XLPVC |
| 1431 | 600V | 105°C | 30/1000 | XLPVC |
| 1452 | 1,000V | 90°C | 26/12 | PVC/Nylon |
| 3173 | 600V | 125°C | 26/9 | XLPE |
| 3266 | 300V | 125°C | 32-10 | XLPE |
| 3271 | 600V | 125°C | 30-1000 | XLPE |
| 3321 | 600V | 150°C | 30-4/0 | XLPE |
